FS120-9 Contitech Industrial Air Bags WBE 300-E1 Weforma Rubber Air Spring For Pick Up

Productdetails:

Plaats van herkomst:	Guangdong, China
Merknaam:	GUOMAT
Certificering:	ISO/TS16949:2009
Modelnummer:	1B1209

Betalen & Verzenden Algemene voorwaarden:

Min. bestelaantal:	6 stks
Prijs:	$49.9-59.9/pc
Verpakking Details:	Sterke doos of zoals klanten nodig hebben
Levertijd:	2-8 werkdagen
Betalingscondities:	T/T, Western Union, L/C
Levering vermogen:	1000 stcs/week

Contact

Gedetailleerde productomschrijving

Lentetype:	Enkel ingewikkeld type	Garantie:	1 jaar
Lentemateriaal:	Metal+Rubber	Toepassing:	Voor industriële apparatuurtoepassing
Gasgat:	G3/4	Hartinfarct:	60mm150mm
Firestone:	W01-M58-6165	Contitech:	FS 120-9
Markeren:	Contitech industrial air spring , WBE 300-E1 rubber air bag , pickup truck air spring

FS120-9 Contitech Industrial Air Bags WBE 300-E1 Weforma Rubber Air Spring For Pick Up

Product Description

Item Name: Air Springs Shock
Item Number: 1B1209
Warranty: 1 Year
Place of Origin: Guangdong, China
Material: Rubber+Metal
Net Weight: 2.4KG
Packing Size: 24*24*22(cm)
Application: For Industrial Equipment Shock Absorption

Technical Data

Top Cover Plate Diameter	135mm
Bottom Cover Plate Diameter	135mm
Gas Hole / Air inlet	G3/4
Rubber Bellows MAX Diameter	215mm
The Working Stroke	MAX 150mm to MIN 60 mm
Top Cover Plate Screw (Nut) Tooth	2XM8X1.25
Bottom Cover Plate Screw (Nut) Tooth	2XM8X1.25
Screw Center Distance of Top Cover Plate	70mm
Screw Center Distance of Bottom Cover Plate	70mm

GUOMAT 1B1209 Original Equipment Manufacturer Information

Description	Air Hole	Center Distance Between Screw and Air Hole	OEM Number
Rubber bellow only			CONTITECH FS 120-9 60479 FIRESTONE STYLE 116 FIRETSONE W01-358-0133
Top/bottom plate M8 (Blind nuts)	G3/4	Center	FIRETSONE W01-M58-6165 CONTITECH FS120-9 2681030000 DUNLOP(FR) 8''X1 S08101 WEFORMA WBE 300-E1 BOSH 822419003 FESTO EB-215-80 NORGREN PM/31081(8''X1)
Top/bottom plate M8 (Blind nuts)	G1/4	Center	FIRETSONE W01-M58-6166 CONTITECH FS 120-9 61358 DUNLOP(FR) 8''X1 S08100 WEFORMA WBE 300-E2 BOSH 822419008
Top/bottom plate M8 (Blind nuts)	G1/4	26mm	PHOENIX SP1B07
